Wednesday 2 October 2024

 Painting the Internal Plywood Walls - 2023 May

     Before painting I had to sand the walls, just a quick-once over to prepare the surface. We had belt sanders, both one that you plug into 240v and one that we put a Ryobi battery in, but they were too large and aggressive for this purpose. We had the Ryobi battery-powered multi-tool which came with a small triangular sanding head and special size pieces of sandpaper that fit, but that was too small to do entire walls with. So we bought a Ryobi battery-powered "palm sander" which was perfect for the job.
          I made myself a special bespoke rig to catch the dust, by attaching the Ryobi battery-powered hand vacuum through a washing machine drain hose, a piece of aluminium bent to the right shape, and some duct tape. By the way, whilst I do like most of the Ryobi products, I do not recommend this vacuum. It is not worth any money as it has little power and always immediately blocks the filter within about 10 seconds of starting to use it.
          Safety equipment was safety glasses and ear muffs. At least my ears were being kept warm on those frosty mornings!
      When I wasn't using the vacuum to keep the dust under control, I wore a very good dust mask. You don't want to put ANYTHING in your lungs, but especially not the dust from treated wood.
          2023 September - We bought some paint which is the undercoat and the primer, and the topcoat was a colour called Twill, just the most common stuff from Bunnings.
          After giving the walls a wipe down with a damp cloth, I painted all the edges and the joins with a brush.
 I used a special cutting-in brush which was AMAZING and I highly recommend. It has an angled cut across the top of the bristles and this lets you paint exact lines at the edges. If you are careful enough you might not need to stick masking tape and newspaper around the edges.
          Something I noticed in the above photo is the holes cut for the plumbing and the electrical wiring. As Josh was cutting and screwing the plywood walls up, he was measuring where the power points and light switches were going to go, and cutting out the right size holes in the right place, and threading the wires through, ready for when the electrician comes back to connect them. Also the water pipes and the gas pipe had to have nice round holes cut to fit in exactly the right place. He did a great job with these tricky details.
          Also in the top left corner you can see that there is still silver sisalation as that section did not yet have the plywood screwed up yet. I was painting what I could as Josh worked in sections around the house.

          Then I painted the walls with a roller. I started with a full-size 30cm roller but found it was very painful to grip with my hands, as you actually have to push quite hard against the wall to get the paint out of the roller and onto the wall, filling in all the little crevices in the wood. So I changed to a small 10cm roller and found that it was fantastic to use. much easier. Also I added a stick to make it longer, so that I could paint the tops of the walls
        Another thing I loved about the small roller is its fantastic little roller tray, with a special end to catch any drips. Much easier to clean too, which is the most annoying part of painting!
          But that was only the base coat - two more coats AND cutting-in to go!

Thursday 26 September 2024

 2023 May

Winter was approaching and we wanted to create a smaller space so that it was easier to be warm in winter. We had discovered by living in the caravan that a small space is actually surprisingly easy to keep warm. Just by our body heat alone, along with jumpers and blankets, we had been comfortable in near zero temperatures. The caravan is under the trees though, and the trees act like a mice warm blanket over the land, so at night the temperatures stay much warmer in comparison to the cleared area around the house. When there are no trees then the warmth of the day just rises up into the sky and it gets much colder much faster. Around the caravan there is never a frost, but down in the clearing we have had quite a few frosts each winter.

We cleared the area where the house is due to bushfire regulations. If it is clear at least 33m around each side of the house, we achieved Bushfire Attack Level 29, which is basically medium level. So while we have safety from bushfire, we also have much colder winter nights. We don't have any form of heating in the house, so the best plan was to just try and create the smallest space to take advantage of our body heat. First step was putting up a ceiling in the first bedroom, as it received winter sun and had all the walls insulated and clad with plywood.

First the ceiling battens had to be put up. These are blue metal which has two sides which are screwed to the roof trusses, and then the middle bit sticks down ready for the ceiling sheets to be screwed to. The photo below shows that there isn't enough room to screw two plywood sheets next to each other. If the screws were any closer to the edge of the plywood, then the wood would split. This means that any point where two sheets join there needs to be an extra wide ceiling batten.
 Josh made these up out of some spare roof truss offcuts we had leftover. The below photo shows the wide batten on the left and the regular ceiling batten on the right.
Another thing we had to figure out was how far apart to put the ceiling battens. After some research we decided that 300mm seemed to be the best distance. This means that with 9 screws along the long edge and 5 rows across, there has to be 45 screws in each sheet. In the below photo you can see the normal ceiling battens on the left side, an extra wide batten at the right-hand end of the plywood sheet, and a gap where the extra ceiling batten hasn't been screwed up yet.
It's a bit tricky lifting a 2.4m long sheet of plywood that weighs about 12 kilograms over your head, up to ceiling height, and holding it exactly in place, predrilling a hole with the drill and then holding a screw and the impact driver and screwing it in - again and again until it stayed up by itself. Whilst balancing yourself and the tools on the ladder. And then screwing in the rest of the 45 screws. Climb down, move the ladder, climb up again, screw in a few more screws, climb down again, move the ladder... etc etc. And then again for the next sheet. We could have hired, borrowed or bought a sheet lifter which could have made the job easier, but these are quite large so they are difficult to transport. Also the sheet lifter would have taken up a lot of room in the house and gotten in the way. Josh was sure that we didn't need one.

Our solution was to have me holding up the sheet with a broom at one end while Josh went up the ladder at the other end and attached some clamps to hold it in place. In the above photo you can see the bags of insulation being temporarily stored in the ceiling. Each single bag contains multiple bags inside, and then each bag is tightly squeezed and sucked shut. When you cut the bag open, air rushes back into the material and it expands hugely. It will go from being maybe 30cm wide to 2 metres wide, it's crazy! They must have really big strong machines that squish these down when they get wrapped. It's a great idea because it saves SO much space when it is being transported and stored.

The below photo shows the second ceiling sheet screwed in place.

The below photo shows the third ceiling sheet in place. The black marks are from the rubber mallet banging it in over the tight gap above the frame for the built-in wardrobe. You can also see in the photo the extra ceiling batten has been added on the right, and a short piece of plywood added at the end to start closing this short side in.
The below photo shows two more long thin pieces of plywood screwed up to fill in the short side of the ceiling.
Here's a photo from the other side of the room.
Now the room is ready to start working towards painting. As you can see these walls have already been filled, with all those funny white spots. Next update coming soon!

Monday 26 August 2024

Solar System

2023 February

    Installing a solar system is pretty complicated, so Josh did a lot of research to make sure that everything was safe and legal. First we needed somewhere under the house to put the connectors that come out of the batteries, and turn the power into something useable. Here is the metal box which has been attached under the house, ready for installing the inverter and other associated paraphernalia. This box is actually a gun safe from Bunnings, as it was a reasonably priced and suitable sized metal box which was readily available. Hanging down in front of it you can see the wiring that the electrician put in during the electricity rough-in. It was placed here ready for connecting to the solar system in June 2022. This would sit and wait for a while before more action happened to it.


     Josh continued putting up the plywood walls and the kitchen looked pretty good. I was working on filling the gaps on the walls as Josh was working on putting up more walls.


     We discovered some of the trickier parts of this material. It didn't like to lay perfectly flat and some sheets stuck out from the sheet next to it by quite a few millimetres.


It was time to try and find a good wood filler. I wanted something that was able to be sanded and painted, but was also had a bit of flexibility in it so that it wouldn't crack when the wood moved. This was one of the products I tried. Also I was hoping that it would be easy to apply into tricky places. This product was very light, as it seemed to have been whipped with lots of air like a mousse. I didn't like it enough to buy it again, especially at nearly $15 for a pretty small amount.


Another product we tried was Spakfilla. It was $12 for a much larger amount. They say on the pack that if it gets a bit hard you can just add a bit of water to get it soft again, which really doesn't seem like something that you want to be having in your walls.


Every screw hole needed to be filled, and they looked like this before filling. They had to be cleaned up of all the splinters around them before filling, so I used a stanley knife or a sander to get them neat and tidy. Also the ones that weren't quite deep enough had to be screwed in a bit further, so I pulled out the drill for that.


And they looked like this after filling. You can see in this shot that I have been sanding the joins between sheets to try and make them flat. This was difficult as the plywood has such thin layers that when sanded, it revealed the layer below it. I had already learned this when sanding the plywood laid down for the floors. Also the plywood would flex when the sander was pressed on it, and then bulge back out when the sander was removed, so it was impossible to get flat joins. Ah well.


This wall alone would have taken a few hours to fill all the holes and the gaps. Easy enough until I had to be crawling around on the floor for the bottom ones, and then up and down the step ladder to reach the top ones, and trying to remember to take everything that I needed with me each time I went up, including knife and drill if needed. For application I tried the spakfilla tool which is a plastic rectangle, and also a flexible knife. Each had its own advantages and disadvantages.


 Then I sanded off the filler to try and make the wall lovely and smooth. I wasn't happy with this product which refused to sand down to a thin layer, instead just removing itself from the area completely and revealing the screw once it was sanded down a little bit. I think it was the Nordsjo expensive mousse one.

Time to try yet another product. This polyfilla was about $17 from Bunnings, but the pack in this picture is an old one I found somewhere.


This wall corner looked a bit of a mess after I tried to fill it in nice and smooth.


Here's an example of a tricky corner join I was filling. It was difficult to fill such narrow gaps and took ages for each section.


I went back and tried again the method of mixing sawdust with wood glue as a filler. It was not very good as it had a lot of shrinkage and then dried very hard and was extremely difficult to sand.


Here is yet another product I tried in the elusive search for a good wood filler.


Here is a pic of me from July 2023 with the sander, continuing to work on the walls a bit more each day.


Yet another product being tested. I mustn't have liked it because I didn't buy it again.


Wait there's more. No I didn't like this one either.


I had added some more safety equipment for the heavy duty sanding, I didn't want to breathing in the plywood or the filler.


My favourite wood filling product by far was the Polyfilla Large Cracks, I even went back and bought a few more of these they were so good. So by my count I tried 8 different fillers before deciding on a good one.


Next time we will be putting up the first ceiling, in May 2023.

Sunday 11 August 2024

 2022 October - Screwing up the Internal Plywood Walls

          Wham bam screw the plywood to the frame, easy peasy! Well, no, unfortunately not. The plywood is 1200mm wide and 2400mm long. The framing widths are - well I measured 10 different widths and then I stopped measuring. Suffice to say that the framing is very random and not designed for easy installation of internal wall panels. So we had to decide whether it was more trouble to cut every single piece of plywood to size to fit the framing, or to install extra framing in the right spot for each sheet to remain whole.

          We had some spare metal ceiling battens so Josh had a go at cutting them to size, screwing them to the framing and and then attaching the plywood. The below image is the back side of the wall.

          This wasn't really ideal as there was too much flex in the plywood joins. There was some further experimentation with wooden battens but nothing was really working. We really didn't know how much support the plywood would need, and could only learn from testing various ideas.

        There is almost no information online about using plywood as a wall material. Everyone assumes that all buildings are a) timber framing and b) gyprock sheeting. We didn't want gyprock or cement board as it just gets holes in it too easily. I think it's a stupid building material and I don't know why it is so popular. Maybe it is to keep the handymen in a job as they are constantly fixing it when it breaks. Also we didn't want the hassle of doing all the plastering over the top. Such a waste of time, money and energy when you can just screw up a plywood sheet and then paint it. You need special tools to install gyp, and it costs more money in the long run.

        Eventually the decision was made to cut every single piece of plywood to size to fit the wall framing. The plywood just had too much bend in it and needed a lot of support. This meant that there was a lot of skinny bits of plywood offcuts. Some of these would be wide enough to be used somewhere else but not all of them. This might mean that the calculations of how much plywood was needed will be off. Oh well.

Below is the bedroom wall with 4 sheets across. There is still a gap across the top that needs filling too.

Next was the living room wall.


Then November rolled around and it was time to start breaking out the insulation. Below you can see the wall behind the insulation is done up until the ceiling battens, And this means that there is insulation installed in the cavity behind the plywood. This sounds easy enough but required a lot of setting everything up to be covered in sheets before starting work to try and reduce the amount of itchy insulation getting on everything. Also in this pic you can see the wall on the right is now finished all the way up to the ceiling. I don't have any pics of the insulation up before the plywood was screwed on because I was avoiding the whole area while Josh was working to try and keep those itchy fibres from getting on me, so you'll just have to imagine it.

Below is the second bedroom, with both the walls on the left and the back having insulation placed inside them.

And below is the two walls on the outside of the bathroom.

Then December rolled around, and the living room walls continued.

In the background of this photo below taken in January of 2023 (of a special visit from an old friend) you can see the kitchen wall done on the left and the living room wall finished to the right.


Next update will be documenting 2023 February, when the solar installation is upgraded.

Tuesday 6 August 2024

 Delivery of plywood and insulation

        Ok let's time travel back to 2022... In September we finally had our delivery of insulation and plywood for internal wall cladding.


    We wanted to get insulation that was
*not itchy
*not expensive
*available locally
*made from environmentally friendly materials eg. recycled
*Not toxic to humans

        After extensive research of all the available options, the best decision was definitely Earthwool, as it was available from Bunnings, a good price and made from 80% recycled glass. Also apparently it doesn't make you itchy. But there was a problem - it was impossible to buy. For one thing, Covid had destroyed supply chains. Also, something about a fire at the Earthwool factory in Asia meant that we could not even special order it from Bunnings. There was none available in Australia apparently. And none coming in the foreseeable future.

          The Bunnings at Lismore said they get their stock from Queensland so they suggested we try the Bunnings at Grafton who get their stock from Sydney, but still there was none available. And geez it's hard to get someone from Bunnings to answer the phone, it just rings out most of the time. And you can't just pop into the store when it's an hour and half drive to Lismore EACH WAY and 2 1/2 hours to Grafton EACH WAY. That's lot of petrol money and an entire day wasted! So we had to work out another product.

        After contacting all the local suppliers the only option was Pink Batts. Definitely not ideal because they are super-itchy, though they are still made from 80% of recycled glass and bio-soluble. This means that any inhaled fibres will dissolve in your lungs and hopefully won't cause bad things to happen to your body.

        For the walls we got R2.0, which is a number which measures the insulating value. We couldn't go higher than this as that is the maximum which fits in our wall width of 7cm. This R value meant that we met the official government requirements for the insulating quality of our house. 18 bags for $60 each was $1000. For the ceilings we got R3.5, which is 17.5cm thick. There is plenty of room in the ceiling so no need to worry about it being too thick. 8 bags for $67 each was about $500.

        As for the plywood, we ordered 7mm for the walls of most of the house. CD Non structural Warrior at just under $50 each for 75 sheets was about $3,500. Each sheet was 2400 x 1200mm. For the bathroom we got Marine ply at 9mm thick, 11 sheets for $114 was about $1,200. They called it DesignerPly Hardwood, whatever that means. Each sheet was 2440 x 1200mm according to the order form, but I think the marine ply was actually a little wider than that.

        So we ordered all of the 2 types of insulation and 2 types of plywood from the one local place as it was simpler, and also as they offered delivery. You can't get delivery from Bunnings without paying hundreds of dollars. This stuff was definitely not fitting in the back of my hatchback! We actually had to wait over 5 weeks after ordering, as the local hardware and timber store were themselves waiting for a delivery from their supplier before they had enough of the right stock for our order. The delivery fee was $66 which is fair considering it was about a 2 hour drive round trip for them, and a while for loading and unloading of the heavy items.

        Finally delivery day rolled around and we asked our wonderful friend to come over and help lift off these sheets. The smaller sheets were about 13kg each, and the larger sheets were nearly 20kg each, which I think is pretty heavy but Josh doesn't think so apparently. I would have loved to be able to help carry them but had to recognise my physical limits so I didn't damage my body. The delivery driver was an old guy who couldn't help carry anything either which was unfortunate. Me and the driver had a chat while the boys were unloading, and oh boy, I could tell he was a Barnaby Joyce voter. That's what they are all like in Tenterfield! He had a young guy as an offsider who was lovely and worked very hard unloading, poor thing had to stop for a drink partway through as it had turned into a bit of a hot day and he was bright red in the face. So I appreciated very much all the work he was doing for us.


        Above is the pile of 7mm plywood, and below is the separate pile of marine ply.


         Then we had a bit of problem when the truck tried to leave, as the driver didn't listen to us when we told him not to back too far down towards the house as it was quite slippery and wet. So of course the truck's tyres were just spinning in the mud. Luckily our wonderful friend had his 4wd ute and was able to give the truck a bit of a pull to get it out. Between the lot of them it turned out that Josh had to be in charge and tell them all where to drive - even though he didn't even have his driver's licence at this point!


     Anyway it was a good day in all, and great to finally have the materials we needed to continue on with finishing the internals of our house. Here's the total of the costs, not including the screws which will be needed to attach to plywood to the walls.

$1000
$500
$3,500
$1,200
equals $6,200

Considering I earn $500 a week that's over 3 months wages!

Wednesday 27 March 2024

Filling Gaps

2022 August

As part of the building requirements for our house, we had to meet bushfire standards. We fulfilled most of these simply by having metal cladding on the outside of the house, but another rule to meet Bushfire Attack Level (BAL) 29 was that there is not allowed to be any gaps smaller than 2mm. This is so that in the event of a bushfire, embers blown by the wind won't be able to get into the house and start a fire. It's a great rule! Many houses burn down because of accumulated dried leaves which are lit by flying embers, so it's best to keep them all out as much as possible.

     We have had to be very inventive as there are very few products available to fill some of the trickier gaps, such as the gap under every single wave of the corrugated iron. This is where the roofing sheets are screwed to the battens. This is a very difficult area to access as you cannot get to it from the outside due to the gutter being in the way. From the inside it's also very difficult to get to as the roof finishes around 400mm from the edge of the house. The best solution we came up with was using roofing silicone to fill all those pesky holes. It was tricky to convince this somewhat runny product to stay upright enough to fill these gaps, but I figured out a few techniques to get it done. So I climbed up the ladder with the caulking gun loaded, stuck my arms into the gaps and did the best I could.


     It was a very time consuming job, and my hands got tired from squeezing the caulking gun at an awkward angle so I could only do a section at a time. The gap was so narrow that my elbow would get stuck if I didn't have it bent exactly the right way to be able to pull it out again! I had to remind my claustrophobia not to panic, especially while balanced on a ladder lol.

     I tested out all the different types of silicone and found that the clear one was the best. Something about the white one made it a completely different texture. Hopefully these will last quite a while, as they are meant to be UV resistant. This will also keep leaves, dust and rain from going inside our eaves, not to mention any birds or insects which might want to make nests in there.


     Unfortunately the gaps above the windows could not be accessed from inside, and could not be siliconed from outside, so I had to come up with another solution.


     We purchased aluminium flashing from Bunnings, and I placed a sheet of Colorbond on it and drew a line with a permanent marker. Then I cut out this line with a pair of tin snips.


     This aluminium flashing is very easy to work with, basically like alfoil but thicker. It wasn't the most perfect fit when I shoved it in, as I literally could not see what I was doing but oh well, better than nothing.

     Also this month was our council building inspection for the frames of the house. This was our first inspection since the holes for the footings. Our council inspector is very nice, and helpfully pointed out a couple of things that we should do, but overall was very happy with our work. What a relief after all the effort we've put in to do things right!

     One problem we had to fix was that the copper pipes for the plumbing was directly touching our metal floor supports and metal cladding The plumber was so used to working with houses which have wooden support beams and cladding that he didn't realise that the two metals touching together would create a reaction that leads to corrosion. In fact the corrosion had already started happening in one place! It was an easy enough fix, I just got an old bicycle tube and chopped it into pieces, unscrewed each screw enough to fit it under, and shoved the rubber in and then screwed the screw back in.


     It meant another day of grubbing around under the house, and sore muscles in very strange places. It's funny how used we get to gravity being a certain way up!


     The building inspector also wanted some more screws WITH A WASHER (apparently makes all the difference) in the edges of the walls where it met the floor, and near doorways, so that was another easy fix.


He also said that the internal framing needed one more bracket for support as per the plans, so Josh bought something suitable from Bunnings and screwed it up.




     Next month - figuring out how to attach the ends of the ceiling battens, and delivery of the insulation and plywood internal cladding.
